Product Characters:
1. Environmental friendly formula:
The raw materials we have used meet the international standards,
non-toxic, environmentally friendly. It is used for a variety of
environmental protection, agriculture and aquaculture waterproof
and anti leakage.
2. Aging resistance property:
With excellent anti-aging, anti ultraviolet and anti decomposition
ability.
3. High mechanical strength:
Good mechanical strength, there are a variety of specifications to
meet the different programs of electrical construction, water
conservancy project waterproof.
4. Chemical stability:
Excellent stability, acid and alkali, anti salt solution, oil,
alcohol and other 80 kinds of chemical medium corrosion, so it is
widely used in sewage treatment, landfill.
5. Puncture resistance:
It has excellent puncture resistance, resist to most of the plant
roots, so HDPE geomembrane is roof planting required products.
6. High impervious coefficient:
With perfect waterproof effect that ordinary waterproof materials
can not match, it is recommended in some high waterproof
requirements of the projects.
7. Fast construction speed:
HDPE geomembrane features high flexibility, with a variety of lay
forms to meet the requirements of different projects, convenient
and fast construction.
8. Low cost:
It adopts new technology, the production process is more scientific
and efficient, so the product cost is lower than the traditional
waterproof material. And it is the best product for water storage
and seepage control
HDPE Geomembrane pond liner TechnicalParameter
ASTM Standard geomembrane
| Spec Properties | Test method ASTM | GMS0.5 | GMS0.75 | GMS1.0 | GMS1.25 | GMS1.5 | GMS2.0 | GMS2.5 |
| Thickness | D5199 | 0.5mm | 0.75mm | 1.00mm | 1.25mm | 1.50mm | 2.00mm | 2.50mm |
| Density (≥ g/cc) | D1505 | 0.940 | 0.940 | 0.940 | 0.940 | 0.940 | 0.940 | 0.940 |
| Tensile Properties (Each direction) (≥) • yield strength • break strength • yield elongation • break elongation | D 6693 Type IV | 8 kN/m 14kN/m 12% 700% | 11 kN/m 20kN/m 12% 700% | 15 kN/m 27 kN/m 12% 700% | 18 kN/m 33 kN/m 12% 700% | 22 kN/m 40 kN/m 12% 700% | 29 kN/m 53 kN/m 12% 700% | 37kN/m 67kN/m 12% 700% |
| Tear Resistance (≥) | D 1004 | 64 N | 93 N | 125 N | 156 N | 187 N | 249 N | 311 N |
| Puncture Resistance (≥) | D 4833 | 160 N | 240 N | 320 N | 400 N | 480 N | 640 N | 800 N |
| Stress Crack Resistance (≥) | D 5397 | 300 hr. | 300 hr. | 300 hr. | 300 hr. | 300 hr. | 300 hr. | 300 hr. |
| Carbon Black Content | D 1603 | 2.0-3.0% | 2.0-3.0% | 2.0-3.0% | 2.0-3.0% | 2.0-3.0% | 2.0-3.0% | 2.0-3.0% |
| Carbon Black Dispersion | D 5596 | Note(1) | Note(1) | Note(1) | Note(1) | Note(1) | Note(1) | Note(1) |
| Oxidative Induction Time (OIT) (≥) (a)Standard OIT - or - (b)High Pressure OIT | D 3895 D 5885 | 100 min. 400 min. | 100 min. 400 min. | 100 min. 400 min. | 100 min. 400 min. | 100 min. 400 min. | 100 min. 400 min. | 100 min. 400 min. |
Packing and Shipping
1. Packing:
PP woven geotextile bags or PE film. Or according to customers
requirements.
2. Delivery:
Within 7-10 days after receiving your deposit.
Samples are for your review.
FAQ
1. Are you trading company or manufacturer ?
A: We are manufacturer.
2. How long is your lead time ?
A: Generally it is 4-5 days.
3. Do you provide samples ? It's free or extra ?
A: Sure ,we woule like to offer the samples for free change , but pls kindly pay the cost of freight by yourself.
4. IS the size and color can be customized ?
A: Sure , the thickness, width, length and color are customzed , but pls talk the details to our sales before the order.
|
|
