| Brand Name : | HASSAN |
| Model Number : | HDPE |
| Certification : | CE ISO9001 |
| Price : | $0.1-1/square meters |
| Payment Terms : | L/C, T/T |
| Supply Ability : | 30000 square meters per day |
| Delivery Time : | 3-5days |
Applications:
(1) Aquaculture:
Using the geomembrane anti-seepage feature; geomembrane liners can
be used as fish ponds, shrimp pond, and other aquaculture.
(2) Landfills:
Bottom landfill liner, landfill sealing cover, leachate regulating
pool liner, etc.
(3) Water Treatment System :
HDPE geomembrane is applied to the adjustment of the power plant
and sewage treatment plants pool; and a series of water treatment
systems.
(4) Mining:
HDPE geomembrane suitable mining: washing pool, pool heap leaching,
heap yard, dissolving tank, tank, storage area, the bottom
line of the tailings seepage control, etc
HDPE Geomembrane pond liner TechnicalParameter
ASTM Standard geomembrane
| Spec Properties | Test method ASTM | GMS0.5 | GMS0.75 | GMS1.0 | GMS1.25 | GMS1.5 | GMS2.0 | GMS2.5 |
| Thickness | D5199 | 0.5mm | 0.75mm | 1.00mm | 1.25mm | 1.50mm | 2.00mm | 2.50mm |
| Density (≥ g/cc) | D1505 | 0.940 | 0.940 | 0.940 | 0.940 | 0.940 | 0.940 | 0.940 |
| Tensile Properties (Each direction) (≥) • yield strength • break strength • yield elongation • break elongation | D 6693 Type IV | 8 kN/m 14kN/m 12% 700% | 11 kN/m 20kN/m 12% 700% | 15 kN/m 27 kN/m 12% 700% | 18 kN/m 33 kN/m 12% 700% | 22 kN/m 40 kN/m 12% 700% | 29 kN/m 53 kN/m 12% 700% | 37kN/m 67kN/m 12% 700% |
| Tear Resistance (≥) | D 1004 | 64 N | 93 N | 125 N | 156 N | 187 N | 249 N | 311 N |
| Puncture Resistance (≥) | D 4833 | 160 N | 240 N | 320 N | 400 N | 480 N | 640 N | 800 N |
| Stress Crack Resistance (≥) | D 5397 | 300 hr. | 300 hr. | 300 hr. | 300 hr. | 300 hr. | 300 hr. | 300 hr. |
| Carbon Black Content | D 1603 | 2.0-3.0% | 2.0-3.0% | 2.0-3.0% | 2.0-3.0% | 2.0-3.0% | 2.0-3.0% | 2.0-3.0% |
| Carbon Black Dispersion | D 5596 | Note(1) | Note(1) | Note(1) | Note(1) | Note(1) | Note(1) | Note(1) |
| Oxidative Induction Time (OIT) (≥) (a)Standard OIT - or - (b)High Pressure OIT | D 3895 D 5885 | 100 min. 400 min. | 100 min. 400 min. | 100 min. 400 min. | 100 min. 400 min. | 100 min. 400 min. | 100 min. 400 min. | 100 min. 400 min. |
Features:
1) Excellent weather-ability, durability and size stability.
2) Good adaptability to high and low temperature, UV resistant and
anti-corrosion.
3) High tensile strength and good elongation, accommodating to
structure movement.
4) Easy installation, solid joint, and no environmental pollution.
5) Good rooting penetration resistance.
6) Service life up to 50 years.
Blue and green geomembrane
Packing and Shipping
1. Packing:
PP woven geotextile bags or PE film. Or according to customers
requirements.
2. Delivery:
Within 7-10 days after receiving your deposit.
Samples are for your review.
FAQ
1. Are you trading company or manufacturer ?
A: We are manufacturer.
2. How long is your lead time ?
A: Generally it is 4-5 days.
3. Do you provide samples ? It's free or extra ?
A: Sure ,we woule like to offer the samples for free change , but pls kindly pay the cost of freight by yourself.
4. IS the size and color can be customized ?
A: Sure , the thickness, width, length and color are customzed , but pls talk the details to our sales before the order.
|
|
